6ES7922-3BF00-0AC0
The 6ES7922-3BF00-0AC0 model product is an industrial grade communication connector module for Siemens S7-300 series PLC. It adopts a modular design and supports high-speed data transmission through PROFIBUS DP and fiber optic interfaces. It has an IP30 protection level and a corrugated aluminum reinforced housing, suitable for 35mm DIN rail installation, can withstand DC9-36V wide voltage input, and is equipped with dual power redundancy protection. This module integrates 6 dual color LED status indicators and supports relay alarm output for fiber optic links and power failures. Its electrical interface has 4000V lightning protection, 1.5A overcurrent, and 600W surge protection capabilities. It has also passed EMC testing certification and supports logic independent dual PROFIBUS DP bus communication. It is compatible with standard rate or rate adaptive configuration and can flexibly form various network topologies such as point-to-point, chain type, star type, redundant dual network, and fiber optic ring network self-healing protection. It is widely used in distributed automation systems in petrochemical, food processing, medical equipment, electronic manufacturing and other fields.
Technical specifcations for 6ES7922-3BF00-0AC0
Interface and communication parameters
Communication interface:
PROFIBUS DP interface: Supports PROFIBUS DP fieldbus communication to meet the requirements of distributed automation systems.
Fiber optic interface: equipped with 155M dual optical interface, supporting fiber optic transmission of PROFIBUS DP bus data, achieving high-speed, long-distance, and anti-interference communication.
Transmission performance:
Transmission rate: Supports standard PROFIBUS DP communication rates, and can manually set all standard rates or rate adaptivity through dip switches, flexibly adapting to different network requirements.
Transmission distance: The fiber optic interface supports long-distance transmission of over 20km, ensuring stable communication in large industrial sites.
2、 Electrical and protective parameters
Power input:
Wide voltage range: Supports DC9-36V wide power input, suitable for different industrial power environments.
Redundancy protection: It has dual power redundancy and isolation protection functions to improve system reliability.
Protection level:
IP30 protection: Complies with the IP30 protection level, effectively prevents dust and foreign objects from entering, and adapts to industrial site environments.
Chassis design: The chassis is reinforced with wavy aluminum to enhance mechanical strength and heat dissipation performance.
3、 Installation and topology parameters
Installation method: Supports 35mm DIN rail installation, easy to integrate into the control cabinet.
Network topology:
Flexible networking: supports various network topologies such as point-to-point communication, chain network, star network, redundant dual network, and fiber ring network self-healing protection.
Redundant dual network: Supports fiber ring network topology with redundant dual networks to improve network reliability and self-healing capabilities.
4、 Function and indication parameters
Status indicator: Equipped with 6 dual color LED status indicators, real-time display of fiber optic link and power status.
Alarm output: Supports relay alarm output for fiber optic link and power failure, facilitating quick fault location and handling.
Function support: Supports logically independent dual PROFIBUS DP bus communication, meeting the multi bus requirements of complex automation systems.
5、 Protection and authentication parameters
Electromagnetic compatibility: Through EMC testing certification, it has the ability to resist electromagnetic interference, ensuring stable operation in complex electromagnetic environments.
Electrical protection: The electrical interface has the ability to protect against 4000V lightning, 1.5A overcurrent, and 600W surge, ensuring the electrical safety of the equipment.
Power isolation: Supports DC1500V power isolation and reverse protection, further improving system reliability.
